    Chemical Resistance Aramid Fiber Good Insulation For Aerospace / Electronic Field

    Aramid fiber , F-12 Aramid fiber


    Aramid fiber is the generic name of a group of synthetic fibers. The fibers offer a set of properties which make them particularly useful in armor, clothing and a wide range of other applications.


    F-12 aramid fiber is one of the “aromatic polyamide” fibers which are used widely in aviation, aerospace, electronic, airship, personal protection and sports product.


    Aramid fibers feature some general characteristics that distinguish them from other synthetic fibers:

    · High strength

    · Low density

    · High flexibility

    · Good resistance to impaction

    · Good resistance to cutting

    · Anti-fatigue

    · Good insulation

    · Good resistance to chemical corrosion

    · Good resistance to low and high temperature

    · Good wave transmission

    · Good size stability


    Chemical and physical property of F-12 Aramid fiber

    Density (g/cm3)1.43±0.1Limited Oxygen index (LOI)35
    Saturated moisture absorption (%)≤3.0Heat expansion index (10-6/K±1
    Glass transition temperature (℃)264Decomposition temperature (℃)
    High temperature performance200℃, strength lowered by 25% for 100 hoursLow temperature performanceStrength maintains the same at -194℃
    Dielectric constant3.4 (23℃)Dielectric loss0.00645 (23℃)
    Creep property60% breaking load, 300 days, creeping increment 0.131%

    Mechanical property of F-12 Aramid fiber

    Model23T44T44THM63T100T130T200T
    Line density(tex)23±244±344±363±4100±5130±5200±5
    Impregnation tensile strength (GPa)≥4.3≥4.3≥4.0≥4.2≥4.2≥4.2≥4.2
    Impregnation elastic module (GPa)≥120≥120≥145≥120≥120≥120≥120
    Elongation (%)≥2.6
